New equipment for sale
CBI 604 Flail Delimber/Debarker
Wood Debarker/Delimber for high production and high quality, uniform wood chips
CBI’s Magnum Force Flail is engineered to be the most rugged and productive delimber/debarker in available in the market.
Designed to meet the needs of logging and wood chipping contractors across the globe, the CBI Magnum Force Flail 604 is equipped with a CAT C-18 765 hp engine and is capable of handling logs up to 24″ in diameter with capacities over 150 tph. Magnum Force Flail is the ideal machine of high production and quality, uniform wood chips or for those within the pulp and paper industry.
Material is fed into and out of the flail chamber by pivoting large diameter and high-torque top feed roll assemblies with position-sensing cylinders to achieve optimum debarking performance. All cylinders are specially designed with heavy-duty clevises and pins for long life and durability. The four-roll flail design provides optimum contact with wood to deliver maximum debarking action. Consisting of four 60″ long by 40″ diameter drums, the flail is capable of running single or dual 8-link chains and speeds of 300-800 rpm.
The 604 is designed with an independent, fully equipped Tigercat T-215. The Tigercat T-215 self-equipped knuckle boom loader comes with a 4.4 L CAT engine and has a 27′ reach. This large capacity, field-proven Tigercat loader allows operators to load more wood per grapple and is the perfect complement to the flail. For short wood processing, the Flail 604 can be supplied with a feed conveyor instead of a loader.
Get More InfoApplication: Soil, Mulch and Compost, Wood Recycling and Forestry
Manufacturer: CBI
Configuration: Portable (Wheeled)
Model: 604 Flail Delimber/Debarker
New/Used: New
Check out the CBI 604 Flail Delimber/Debarker in action!
Performance Highlights
- Four roll flail design for optimism debarking action and production level while reducing fiber loss and chain wear. Specifically designed to work in unison with the CBI Disc Chipper 754.
- Fully enclosed design for debris containment to reduce maintenance and fire hazard.
- Completely independent, fully-equipped Tigercat T-215 loader.
- Very large, long and deep chain curtain to prevent bark and branches from “surfing” and discharging with the debarked logs
- Designed for “B-train” configurations with direct feed into a CBI Disc Chipper. A complete in-woods pulp-quality chip processing solution.
- 13′ wide x 12″ high hydraulic debris conveying ram for complete residue removal.
- Largest feed opening 60″ x 24″ for the highest throughput.
- Large diameter, high torque feed rolls (2 upper, 3 lower)
- Can we equipped with an optional
- Optional track-mounted unit available
Benefits
Enclosed system
The completely enclosed system on the CBI 604 Magnum Force Flail has no exposed drive components, which effectively contains debris, reduces maintenance downtime and lowers the fire risk.
High production
The 604 flail debarker is designed with full width, large diameter feed rollers, which ensure a continuous, high production feed. As a result, production rates up to 150 tons per hour can be achieved.
Maximum debarking action
CBI’s four-roll flail design provides optimum contact with wood to deliver maximum debarking action. Consisting of four 60″ long by 40″ diameter drums, the flail is capable of running single or dual 8-link chains and speeds of 300-800 rpm
Sophisticated feed system
Material is fed into 604 flail bebarker and out of the flail chamber by pivoting large diameter and high-torque top feed roll assemblies with position-sensing cylinders. All cylinders are specially designed with heavy-duty clevises and pins for long life and durability. Infeed rolls monitor the height of incoming material and automatically adjust the height and speed of flail rolls, improving debarking by reducing chain wear, fiber loss, and fuel consumption.
