New equipment for sale
GOMACO GT-3200 Slipform Paver
A compact three-track curb and gutter machine that also slipforms barrier wall and flat slab, with simultaneous trim and pour.
The GOMACO GT-3200 is a compact three-track curb and gutter machine with the versatility to take on more. It slipforms curb and gutter, barrier wall, and flat slabs, changing profiles through GOMACO’s quick-detach mold, and its hydraulically telescoping frame moves the right leg up to 36 in. (914 mm) laterally to suit changing job-site requirements. G+ controls run the machine from stringline, 2D, or 3D guidance.
The GT-3200 is fast. Two-speed track motors give job-site mobility up to 136 fpm (41.5 mpm) and paving speeds up to 50 fpm (15.2 mpm), among the fastest tracking speeds in the industry. Its front-steer capability and All-Track Drive let it slipform a radius as tight as 24 in. (610 mm).
The machine is built to keep pouring cleanly. A 5.8 ft. (1.77 m) GOMACO-designed charging auger, or an optional 13.5 ft. (4.1 m) charging conveyor, feeds concrete to the hopper, and the hopper carries extra capacity so the machine can slipform a full radius without waiting on a truck to reposition. With the simultaneous trim-and-pour setup, a sectionalized trimmerhead with 36 in. (914 mm) of sideshift and 14 in. (356 mm) of vertical lift trims the grade and clears obstacles while the mold pours right behind it, for exact grade and maximum concrete use.
Get More InfoApplication: Concrete Paving
Manufacturer: GOMACO
Configuration: Mobile (Tracked)
Model: GT-3200 Slipform Paver
New/Used: New
Performance Highlights
- Slipforms curb and gutter, barrier, and flat slab
- Compact three-track machine
- Simultaneous trim-and-pour in one pass
- Slipforms a radius as tight as 24 in. (610 mm)
- Telescoping frame, 36 in. (914 mm) right-leg shift
- Quick-detach mold for fast profile changes
- Job-site travel to 136 fpm (41.5 mpm)
- Paving speed to 50 fpm (15.2 mpm)
- 5.8 ft. (1.77 m) charging auger standard
- Optional 13.5 ft. (4.1 m) charging conveyor
- Trimmerhead sideshift 36 in. (914 mm)
- G+ control from stringline, 2D, or 3D guidance
Benefits
Curb and gutter, and more
The GT-3200’s core job is curb and gutter, but the same compact machine slipforms barrier wall and flat slabs too. Molds are side-mounted for minimum offset, GOMACO’s quick-detach system swaps profiles fast, and the telescoping frame shifts the right leg 36 in. (914 mm). Roll-over, stand-up, and depressed curb are all in its range.
Simultaneous trim and pour
The GT-3200 trims the grade and pours in one pass. A sectionalized trimmerhead with 36 in. (914 mm) of sideshift and 14 in. (356 mm) of vertical lift prepares the grade and clears obstacles while the mold slipforms right behind it. The result is exact grade and maximum concrete use, with the operator positioned to watch both.
Fast on the job and to the next
Two-speed track motors move the GT-3200 up to 136 fpm (41.5 mpm) between pours and pave up to 50 fpm (15.2 mpm), among the fastest tracking speeds in the industry. Front-steer capability and All-Track Drive slipform a radius as tight as 24 in. (610 mm), which suits the machine to parking lots, subdivisions, and other tight-radius work.
Keeps the pour going
The hopper is sized for extra concrete capacity, so the machine can slipform a complete radius without stopping for a truck to reposition. A 5.8 ft. (1.77 m) charging auger feeds the hopper as standard, with an optional 13.5 ft. (4.1 m) conveyor for more reach, and a water system handles cleanup at the end of the pour.
Why GOMACO
Concrete paving since 1965
GOMACO has built concrete paving equipment out of Ida Grove, Iowa since 1965 and holds ISO 9001:2015 certification. The paving line covers widths up to 50 feet (15.2 m) and depths to 19 inches (483 mm), and the same machines run on interstate mainline, airport runways, city streets, and canal work around the world.
G+ Operating System
G+ is proprietary, developed by GOMACO’s own control engineers rather than adapted from an off-the-shelf platform. It uses two-way communication between the paver and its accessories, closed-loop electronic and hydraulic control, and instant digital feedback. Contractors moving up from a GP-4000 can carry their existing attachments and sensors straight onto a new GP4.
Family owned from the start
GOMACO is still owned and run by the family that started it. Harold and Gary Godbersen founded Godbersen Manufacturing Company in 1965, and a third generation of the family is in the business today. Roughly 350 people build every machine in Ida Grove, Iowa, across more than 500,000 sq. ft. (46,450 m²) of plant, office and engineering space.
