High production modular jaw crushing plant

Cedarapids MJ55 Modular Jaw Crusher Plant

Cedarapids MJ55 modular jaw crusher
  • This field is for validation purposes and should be left unchanged.

Designed around the proven, high-performance Cedarapids® JW55 jaw crusher, the MJ55 Modular Jaw Crusher is designed for large quarries or contractors that want a stationary type design without the complexity of a normal stick-built plant. The modular structure can be transported in standard shipping containers plus a flat rack for the crusher and can be bolted together quickly on-site with basic tools. The three configurations offered for the feed hopper allow for the optimum size to match up to the equipment that is being used to load the machine.

Key Features

  • Fast set-up time
  • Ease of operation
  • On-site assembly with minimal wiring
  • Integrates with existing plant configuration
  • All electric
  • Compact – can be transported in containers and by road
  • Robust, weather-protected panels with user-friendly controls
  • Galvanized steel structures including walkways, stairs and guard rails
  • Extra heavy-duty I-beam frames
  • CE-compliant modules, structures and components
  • Manual/Automatic one touch startup with start sequencing

Main Components

  • Galvanized Modular Structure, steps and guardrails

Durability

  • Fully Galvanized Structure
  • All electric
  • Heavy Duty Nema Type 12 / IEC60529 Control Panel (Hoffman style)
  • Rock shelves or bolt in liners in high wear areas
  • Set Up
  • Easy assemble and disassemble
  • Pre-assembled sections to enable quick set up time and as few lifts as possible from container
  • Lift points on all parts and assembles over 50lbs

Transport (Standard Build)

  • 4 X 40’ Standard Open Top Container
  • 1 X 40’ Flat Rack

Options

  • Electrical Switch Gear
  • Off Plant conveyor starter kit
  • 16’ (4.8m) Extended Sloped Hopper Wings
  • 18’ (5.5 m) Wide Truck Loading Hopper (Rock box style)
  • Magnet

Key Model Attributes

Capacity

Up to 680 tph

Weight

56,000 kg

Motor size

200 hp / 150 kW
