Open circuit portable cone crushing plant

Cedarapids CRC450X Portable Cone Crusher Plant

Cedarapids 450x cone crusher
  • This field is for validation purposes and should be left unchanged.

The Cedarapids® CRC450X cone plant is built for portability, especially for applications involving hard abrasive materials. This open circuit plant can be tied in with any portable crushing operation. They are commonly set up in secondary, tertiary, and quaternary crushing positions. The CRC450X is an all electric plant which can easily be tied into new or existing systems. CRC450X plants are available with a variety of options including feed conveyors and extra length undercrusher conveyors.

Standard Features

  • High-efficiency MVP450X cone crusher with ElJay® Rollercone® roller bearing construction
  • Single 400 hp (296 kW) crusher motor with easy adjust cone crusher drive
  • Mesh cone hopper extension
  • “Straight-line” undercrusher conveyor; 42″ x 34’6″ (1067 x 10,515 mm); 15 hp (11 kW)
  • 3-ply conveyor belt with vulcanized belt splice
  • Service platforms around crusher with guard rails and access ladder
  • Easy maintenance features;
    • Ratchet cone drive belt tensioning
    • Conveniently located grease banks
    • Ground access cone lubrication module
    • Large undercrusher hinged access panel
  • Emergency stop buttons on both sides of frame
  • Triple axle spring suspension
  • Drop-down rear stabilizing legs
  • Twelve 295/75 R22.5 tires
  • Lockable 4′ (102 mm) long side-mounted storage box

Optional Equipment

  • Oversized quick release cone surge hopper
  • Crusher overflow chute to undercrusher conveyor
  • *Longer undercrusher conveyor with hydraulic adjust discharge; 42″ x 45′ (1067 x 13,716 mm); 15 hp (11 kW)
  • *Feed conveyor with hydraulic positioning (LH or RH); 36″ x 36′ (914 x 10,973 mm); 15 hp (11 kW)
  • Conveyor skirt boards
  • Removable electrical switchgear panel with crusher soft start and push-button station
  • Hydraulic leveling or run-on jacks (gas, 12V or 24V powered)
  • Power cables and quick disconnects
  • Oversize 315/80 R22.5 tires
  • Dust suppression water spray system
  • Flexco style belt wiper

*Requires hydraulic leveling or run-on jacks option

Key Model Attributes

Capacity

Up to 645 tph

Weight

47,000 kg

# of Axles

3

Motor Horsepower

400 hp
